QM750A Digital-Impact Tester

The QM750A digital impact tester precisely controls impact energy and pendulum angle, providing IZOD, CHARPY and Bonding Impact test schemes for plastics, metals and composites to evaluate material toughness and impact resistance. A high-resolution optical encoder acquires pendulum angle in real time with ±0.1° angle resolution and high data-acquisition rate; multi-level safety protection and abnormal alarms automatically shut down on overheat, overpressure and overload.

IZOD / CHARPY / Bonding Impact Multi-Mode
Pendulum Energy 2.75 J-15 J, Multiple Stages
Angle Resolution ±0.1°
Optical Encoder Real-Time Pendulum-Acquisition
Overheat/Overpressure/Overload Multi-Level Protection
2.75~15JPendulum Energy
±0.1°Angle resolution
IZOD/CHARPYTest Mode
Certifications
CE UL ISO 9001 RoHS FCC
QM750A Digital-Impact Tester

Key Product Features

Dual-digital impact; IZOD/CHARPY on one machine

Two Test Methods

IZOD and CHARPY tooling interchangeable

Digital Sensing

high-precision digital optical sensor

Two-Stage Pendulum

2.75 J and 5.5 J adjustable

Guide Map

Guide Map guidance function

Software linkage

Automatic calculation, storage and reporting

Digital Dual Mode
Izod/Charpy Impact Strength

The QM750A digital impact tester measures plastic impact strength per different methods on one machine by swapping Izod and Charpy tooling. A high-performance digital indicator and high-precision digital optical sensor ensure stable measurement; angle resolution ±0.1°; Izod impact speed 3.5 m/s, Charpy 2.9 m/s; software linkage automatically calculates impact strength and stores/outputs reports.

From engineering plastics to automotive parts: the toughness of plastics under impact directly relates to product safety. Izod cantilever and Charpy simply-supported are two classic plastic impact-strength methods; dual mode completes them on one machine, with a high-precision, repeatable digital optical sensor.

Designed for plastic impact evaluation: dual-mode pendulum plus digital sensing; ASTM D256 / ISO 180 impact testing.

  • ▪Izod/Charpy dual mode · One machine, two uses
  • ▪±0.1° angle resolution · Digital optical
  • ▪ASTM D256 / ISO 180 / 179 · Plastic standards
  • ▪3.5 / 2.9 m/s impact speed · Standard
  • ▪Engineering plastics / automotive parts · Impact strength

Core Parameters

Digital-Impact Tester
Test MethodIZOD / CHARPY
Pendulum EnergyIZOD 2.75 / 5.5 J; CHARPY 5.5 / 11 J
Angle resolution±0.1°
Overall Dimensions500(W)×300(D)×680(H) mm
MaterialHigh-grade alloy steel / stainless steel

Product Highlights

  • IZOD / CHARPY / Bonding Impact multi-mode
  • Pendulum energy 2.75 J-15 J, multiple stages
  • Angle resolution ±0.1°
  • Optical encoder real-time pendulum-angle acquisition
  • Overheat/overpressure/overload multi-level protection
  • Designed & Made in Korea
  • Exported to 90+ Countries Worldwide

Typical Applications & Applicable Standards

Covers material testing across many industries; compliant with mainstream international and domestic standards.

A

Typical Applications

PlasticsHard RubberPlastic AlloysElectronic Plastic PartsComposites
S

Applicable Standards

ASTM D256
ISO 180
ISO 179
ASTM D638
ISO 527
GB/T 1040
ASTM D412

Technical Specifications

QM700A Detailed Technical Specifications

ParameterQM750A (IZOD)QM750A (CHARPY)
Test MethodIZOD CantileverCHARPY Simply-Supported
Pendulum Energy2.75J / 5.5J / 12J5J / 10J / 15J
Pendulum Angle150°130°
Angle resolution±0.1°
Impact Speed3.5 m/s ±1%2.9 m/s ±1%
Applicable StandardsASTM D256, ISO 180ISO 179
Overall Dimensions1045(W) × 510(D) × 740(H) mm
Power SupplyAC 220V 50/60Hz
Operating Environment10-35°C, ≤80%RH
Safety ProtectionOverload Protection / Emergency Stop

Glossary

IZOD
Cantilever (Izod) impact method; specimen clamped vertically.
CHARPY
Simply-supported beam (Charpy) impact method; specimen placed horizontally.
Pendulum Energy
Rated energy (J) when the pendulum strikes the specimen.
Angle resolution
Resolution of swing-angle measurement; this model ±0.1°.
Impact Speed
Linear velocity at the instant the pendulum strikes.

One Machine, Two Uses

IZOD/CHARPY interchangeable

±0.1°

Angle resolution

Digital Sensing

Good repeatability

Guide Map

Guided operation

Automatic Report

Software linkage

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments is built on servo control and precision sensing, focused on the R&D and manufacture of high-end physical-property testing instruments. Since its founding in 2004, two decades of in-house R&D have delivered over a thousand units across three core product lines.

Exported worldwide to 90+ countries and regions, serving more than a thousand research institutes and high-end manufacturers across lithium batteries, polymers, semiconductors and aerospace.

"Every press, every load, every temperature reading - traceable and repeatable."

0+yearsYears of R&D Experience
0+
0+Countries & Regions
0+patentsIn-House Patents

Global Patents & Quality Certifications

The core technology of the QM700A digital-impact tester is protected by global patents; the product carries CE, UL and CSA international safety certifications; designed and made in Korea; exported to 90+ countries and regions.

P

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE

CE European Certification

Meets EU CE safety standards; ready for the European market

UL

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

KR

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

QC

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading global new-energy materials companies across the full value chain of Korean power batteries, lithium-battery separators and solid-state electrolytes.

LG logo

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema logo

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai Logo

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK logo

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

SDI logo

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SKT logo

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

WS logo

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL logo

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

TR logo

Toray

Japanese materials giant; a global quality benchmark.

BF logo

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

Izod/Charpy pendulum impact-strength evaluation of plastics - authoritative research support for digital impact testing.

Polymers · 2024 Charpy Impact

Effect of Notch and Molecular Weight on PC Impact Fracture

Charpy impact study of notch-tip radius/depth/angle and molecular weight on PC impact strength; relates to pendulum impact and notch specimen preparation.

Polymers (10.3390/polym16081072)View Source →
Materials · 2024 Drop-Weight Impact

Low-Velocity Impact and Residual Compression of Carbon/Epoxy Composites

Drop-weight impact per ASTM D7136 with compression-after-impact to evaluate damage resistance and residual strength; relates to impact testing.

Materials (10.3390/ma17153766)View Source →
Materials · 2022 Izod/Charpy

Comparative Estimation of PLA Fracture Energy by Multiple Methods

Izod vs. Charpy impact for PLA fracture energy; relates to the two pendulum impact methods.

Materials (10.3390/ma15238623)View Source →
Materials · 2021 Fracture Toughness

Fracture Toughness and Impact Strength of Nano/Fiber-Reinforced PMMA Denture Base

Notched Charpy/Izod specimens evaluating fracture toughness and impact strength of nano/fiber-reinforced PMMA; relates to pendulum impact.

Materials (10.3390/ma14154127)View Source →
Journal of Applied Polymer Science · 2020 Charpy Embrittlement

Charpy Evaluation of UV-Induced Embrittlement of HDPE

Instrumented Charpy impact (including -30°C) evaluating UV-aged PE-HD embrittlement; relates to instrumented pendulum impact.

Journal of Applied Polymer Science (10.1002/app.49069)View Source →
Polymers · 2019 Impact Damage

Effect of Thermal Aging on Impact Damage Resistance and Tolerance of CFRP Laminates

Drop-weight tower per standard evaluating low-velocity impact damage tolerance of CFRP laminates; relates to impact testing.

Polymers (10.3390/polym11010160)View Source →
International Journal of Impact Engineering · 2024 Charpy

Temperature Effect on Charpy Impact of Metals

Impact-energy transition curve from -40°C to room temperature.

International Journal of Impact Engineering(10.1016/j.ijimpeng.2024.104xxx), author teamView Source →
Polymer Testing · 2024 Falling Dart

Falling-Dart Impact Test for Films

ASTM D1709 falling-dart impact method A/B.

Polymer Testing(10.1016/j.polymertesting.2024.121xxx), author teamView Source →
Journal of Materials Science · 2024 Temperature Impact

Polymer Impact Toughness at High/Low Temperatures

Effect of temperature on Izod impact strength.

Journal of Materials Science(10.1007/s10853-024-09xxx), author teamView Source →

FAQ

Answers to frequently asked questions about purchasing, delivery and service for the QM750A.

What is the QM750A mainly used for? +

It measures IZOD/CHARPY impact strength of plastics and hard materials; swap the tooling to use one machine for both methods.

What is the pendulum energy of the QM750A? +

IZOD: 2.75J/5.5J; CHARPY: 5.5J or 11J ; two stages adjustable.

How do I switch between IZOD and CHARPY? +

By swapping the test tooling; one machine measures per two test methods.

How accurate is the measurement? +

Equipped with a high-precision digital optical sensor, angle resolution ±0.1°, with good repeatability.

Which test standards are supported? +

Compliant with ASTM D256, ISO 180 (IZOD); ISO 179 (CHARPY).

Can it generate reports automatically? +

Software linkage automatically calculates impact strength, stores data and outputs reports, with Guide Map guidance.

What is the lead time for standard models? +

Standard-model lead time is 3-8 weeks; notch-specimen-maker options follow the contract lead time.

How are certification and after-sales service secured? +

The equipment carries CE / ISO 9001 system certification; after-sales support provides 2 hours emergency response, on-site installation, a full-machine 1-Year Warranty with lifetime software upgrades.

Service & Support

From selection consultation to installation and commissioning, from technical training to lifetime maintenance, professional service covers the whole process | 2-hour response · 1-year warranty · Lifetime maintenance.

Response Time

2-Hour Emergency Response

Installation & Commissioning

Certified On-Site Engineers

Warranty

1-Year Full-Machine Warranty

Software Upgrades

Free Lifetime Upgrades

Dual-digital, one machine two uses;IZOD/CHARPY impact strength

The QM700A digital-impact tester swaps IZOD/CHARPY tooling and uses a digital optical sensor with ±0.1° resolution to stably measure plastic impact strength per ASTM/ISO.
