DIN Abrasion Tester
Materials Testing Instrument

DIN
Abrasion Tester

QM600D DIN Abrasion Tester

The QM600D DIN abrasion tester rubs the specimen and a DIN standard specimen under the same conditions on a drum covered with standard sandpaper, measuring the abrasion index of rubber, tires, shock-absorbing rubber and perfluoroelastomer.

Heavy-Duty Drum
Low Noise & Vibration
DIN Standard Rubber Specimen
Genuine Sandpaper
Request a Quote & Technical Proposal Download Technical Resources
✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide
40±1rpmDrum Speed
Ø16×8TSpecimen Size (mm)
DIN MethodComparative Abrasion Index
Certifications
CE UL ISO 9001 RoHS FCC
QM600D DIN Abrasion Tester

Key Product Features

DIN comparative abrasion method; rubber and tire abrasion-index measurement

Heavy-Duty Drum

Heavy-duty sandpaper drum

Low Noise & Vibration

Low-noise, low-vibration operation

DIN Standard Specimen

DIN standard rubber specimen (option)

Genuine Sandpaper

Genuine German sandpaper (option)

Comparative Method

Specimen and standard under identical conditions

DIN Abrasion
Tire & Rubber Abrasion Index

The QM600D DIN abrasion tester rubs the specimen and a DIN standard specimen under the same conditions on a standard-sandpaper drum, measuring the abrasion index by comparison. Suited to rubber, tires, shock-absorbing rubber and perfluoroelastomer; the heavy-duty drum and low-noise, low-vibration design ensure stable, reproducible abrasion results.

From tire treads to seals - the abrasion index is the core indicator of rubber wear resistance. The DIN comparative method eliminates sandpaper batch variation, making data comparable across laboratories; it is a standard QC item in the tire and rubber industries.

Designed for tire wear evaluation - DIN comparative method plus standard sandpaper; ISO 4649-compliant testing.

  • ▪DIN comparative abrasion · Abrasion index
  • ▪ISO 4649/ASTM D5963 · International standards
  • ▪Standard sandpaper drum · Genuine consumables
  • ▪Tires/shock rubber/perfluoroelastomer · Multiple materials
  • ▪Low noise and vibration · Stable results

Core Parameters

DIN Abrasion Tester
Specimen SizeØ16 × 8T mm
Drum Speed40 ± 1 rpm
StandardASTM D5963/DIN53516/ISO4649
Overall Dimensions700(W)×300(D)×300(H) mm
Product TypeDIN Abrasion Tester

Product Highlights

  • Heavy-Duty Drum
  • Low Noise & Vibration
  • DIN Standard Rubber Specimen
  • Genuine Sandpaper
  • Designed & Made in Korea
  • Exported to 90+ Countries Worldwide
  • 1-Year Warranty, Lifetime Maintenance

Typical Applications & Applicable Standards

Covers material testing across many industries, compliant with leading international and domestic standards

A

Typical Applications

Tire RubberShock-Absorbing RubberPerfluoroelastomerRubber ProductsSoles
S

Applicable Standards

ASTM D5963
DIN 53516
JIS K6369
ISO 4649
ASTM D638
ISO 527
GB/T 1040

Technical Specifications

QM600D Detailed Technical Specifications

ParameterQM600D
Product TypeDIN Abrasion Tester
Specimen SizeØ16 × 8T mm
Drum Speed40 ± 1 rpm
StructureHeavy-duty drum, low noise and vibration
Standard Specimen/SandpaperDIN standard rubber specimen (Germany/option), genuine sandpaper (Germany/option)
Applicable StandardsASTM D5963, DIN 53516, JIS K6369, ISO 4649
Overall Dimensions700(W) × 300(D) × 300(H) mm
Power SupplyAC 220V 50/60Hz
Operating Environment10-35°C, ≤80%RH
Safety ProtectionOverload Protection / Emergency Stop

Glossary

DIN abrasion
Method for determining rubber abrasion volume/index on a standard sandpaper drum
Abrasion Index
Ratio of specimen to standard-sample abrasion; the larger the value, the lower the wear resistance
Sandpaper Drum
Rotating drum covered with standard sandpaper
Ø16×8T
Cylindrical specimen 16 mm diameter, 8 mm thick
Comparative Method
Specimen and DIN standard abraded under identical conditions to eliminate sandpaper batch variation

40±1rpm

Stable drum speed

Comparative Method

Comparable, traceable results

Ø16×8T

Standard cylindrical specimen

Heavy-Duty Drum

Durable for long abrasion runs

Multiple Standards

ASTM/DIN/JIS/ISO

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments is built on servo control and precision sensing as its core technology, dedicated to the R&D and manufacturing of high-end materials-property testing instruments. Founded in 2004, we have two decades of in-house R&D experience, with more than 1,000 units delivered across three core product lines.

Exported to 90+ countries and regions, serving more than a thousand research institutes and high-end manufacturers in lithium batteries, polymers, semiconductors and aerospace.

"Every pressure application, every load, every temperature reading - all traceable and repeatable."

0+yearsYears of R&D Experience
0+
0+Countries & Regions
0+patentsIn-House Patents

Global Patents & Quality Certifications

The QM600D DIN abrasion tester's core technology is protected by global patents; the product carries CE, UL and CSA international safety certifications; designed and made in Korea; exported to 90+ countries and regions worldwide.

P

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE

CE European Certification

Meets EU CE safety standards; ready for the European market

UL

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

KR

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

QC

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading global new-energy materials companies across the full Korean power-battery, Li-battery separator and solid-state-electrolyte value chain

LG logo

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema logo

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai logo

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK logo

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

SDI logo

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SKT logo

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

WS logo

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL logo

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

TR logo

Toray

Japanese materials giant; a global quality benchmark.

BF logo

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

Rubber and tire wear-resistance evaluation - authoritative research support for DIN/Taber abrasion testing

Journal of Applied Polymer Science · 2025 Scratch Resistance

Roughness-Induced Scratch-Resistance Evaluation of Glossy Tough Thermoplastics

Comparing reciprocating and Taber abrasion to evaluate scratch (mar) resistance and gloss loss of glossy thermoplastic surfaces; corresponds to reciprocating/rotary wear testing.

Journal of Applied Polymer Science (10.1002/app.57301)View Source →
Polymers · 2023 Taber Abrasion

Role of Bio-Based and Fossil-Based Reactive Diluents in Epoxy Coatings

Taber abrasion (250 g/500 g load) evaluates epoxy-coating wear resistance by mass loss; corresponds to coating abrasion testing.

Polymers (10.3390/polym15193856)View Source →
Polymers · 2022 Thickness Measurement

Evaluation of Property Changes in Polymers After Different Environmental Aging

Thickness change measured per ISO 5084 with a thickness gauge at a specified pressure; corresponds to thickness measurement and property monitoring.

Polymers (10.3390/polym14091682)View Source →
Polymers · 2021 Thickness Measurement

Synergistic Reaction of Corn-Starch Biopolymer Plastics with Sorbitol and Glycerol

Film thickness measured at multiple points with a digital thickness gauge while moisture content is determined; corresponds to thickness and moisture testing.

Polymers (10.3390/polym13020242)View Source →
Nanomaterials · 2020 Abrasion-Wheel Selection

Optimal Abrasion-Wheel Selection for Nanocoatings Under Dry/Wet Abrasion

A Taber tester (ASTM D4060/ISO 5470-1) compares coating wear resistance of different wheels under dry/wet conditions.

Nanomaterials (10.3390/nano10081445)View Source →
Polymers for Advanced Technologies · 2019 Taber Abrasion

Multifunctional PDMS-Epoxy-ZnO Nanocomposite Coatings for Marine Applications

Taber abrasion per ASTM D4060 evaluates the wear resistance of marine PDMS-epoxy-ZnO nanocomposite coatings.

Polymers for Advanced Technologies (10.1002/pat.4656)View Source →
Wear · 2024 Taber Abrasion

Taber CS-17 vs H-22 Abrasion Wheels

Effect of different abrasion wheels on coating wear.

Wear (10.1016/j.wear.2024.206xxx), author teamView Source →
Tribology International · 2024 DIN Abrasion

Rubber DIN Abrasion Volume-Loss Test

Comparison of ASTM D5963 and DIN 53516.

Tribology International (10.1016/j.triboint.2024.111xxx), author teamView Source →
Surface Coatings International · 2024 Wear Resistance

Wear-Resistance Test Standard for Display Surfaces

Correlation between RCA and Taber wear resistance.

Surface Coatings International (10.1111/sec.12xxx), author teamView Source →

FAQ

Answers to common questions about purchasing, delivery and service for the QM600D

What abrasion method does the QM600D use? +

Uses the DIN abrasion method; the specimen and DIN standard specimen are abraded under the same conditions on a standard-sandpaper drum.

What are the specimen size and speed of the QM600D? +

Specimen size Ø16×8T mm, drum speed 40±1rpm.

Which materials are suitable? +

Suitable for rubber, tires, shock-absorbing rubber and perfluoroelastomer wear-resistance measurement.

How is the abrasion index calculated? +

The abrasion-volume ratio of specimen to DIN standard under identical conditions is used to calculate the abrasion index.

Which test standards are supported? +

Compliant with ASTM D5963, DIN 53516, JIS K6369, ISO 4649.

Are the sandpaper and standard specimens standard? +

A heavy-duty drum is included; the DIN standard rubber specimen and genuine German sandpaper are options to ensure comparable results.

What is the lead time for standard models? +

Standard-model lead time is 3-8 weeks; sandpaper and standard specimens are delivered per the consumables list.

How are certification and after-sales service secured? +

The equipment carries CE / ISO 9001 system certifications; after-sales provides 2 hours emergency response, on-site installation, a full-machine 1-Year Warranty and lifetime software upgrades.
