Internal Mixer
Materials Testing Instrument

Heating Internal Mixer Precise, Reliable Testing

QM310S Heating Internal Mixer

The QM310S heating internal mixer is a closed, high-filler mixing unit for rubber and plastic raw materials, aimed at formulation R&D and small-batch trial mixing; rotor shear disperses fillers evenly into the polymer.

The heated chamber with real-time torque/temperature monitoring lets operators observe powder uptake, dispersion and curing/plasticizing during mixing, supporting rheology R&D and formulation evaluation.

Closed mixing keeps dust low and batches small and flexible; paired with an open mill for sheeting and a curemeter for testing, it forms a complete mixing-to-evaluation process chain.

Closed high-filler mixing
Heated Chamber
Torque/temperature monitoring
Rheology R&D
Flexible Small-Batch
Request a Quote & Technical Proposal Download Technical Resources
✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide
150 cc Batch Capacity
Max 500 N·m Max. Torque
Max 150 rpm Rotor Speed
Certifications
CE UL ISO 9001 RoHS FCC
QM310S heating internal mixer

Key Product Features

Rubber processing - authoritative research confirming the key role of curing/mixing in rubber performance evaluation.

Closed High-Filler

Closed mixing suits high-filler formulations with low dust and even dispersion.

Heated Chamber

The chamber is heated and temperature-controlled to simulate real processing thermal history.

Process Monitoring

Torque and temperature are displayed in real time and the whole mixing process is logged.

Rheology R&D

Observe powder uptake and dispersion to guide formulations and process windows.

Flexible Small-Batch

Small batches and fast cleaning, ideal for R&D and multi-formulation comparison.

Closed Internal Mixer
Small-Batch Trial Mixing for Formulation R&D

The QM310S heating internal mixer is a closed mixing unit for rubber and plastic raw materials; rotor shear disperses fillers, additives and polymers evenly for formulation R&D and small-batch trial mixing. The heated chamber with real-time torque/temperature monitoring lets operators observe powder uptake, dispersion and plasticizing during mixing to capture rheology and process-window information.

From formulation screening to process optimization - the internal mixer's closed mixing keeps dust low and batches small and flexible, while the torque curve reflects material dispersion in real time. Paired with the QM300 open mill for sheeting and a curemeter for testing, it forms a complete mixing-to-evaluation chain - a core instrument for polymer formulation R&D.

Designed for formulation R&D evaluation - closed mixing plus real-time torque monitoring for small-batch rheology and process windows.

  • ▪Closed mixing · low dust
  • ▪Real-time torque/temperature · visible process
  • ▪Heated chamber · high-filler dispersion
  • ▪Small-batch flexible · formulation R&D
  • ▪Rubber/plastic/filler · internal mixing

Core Parameters

Heating Internal Mixer
Product Type Heating Kneader
Batch Capacity 150 cc
Max. Torque Max 500 N·m
Rotor Speed Max 150 rpm
Temperature Control3-zone / 4-point independent control

Product Highlights

  • Closed high-filler mixing
  • Heated Chamber
  • Torque/temperature monitoring
  • Rheology R&D
  • Flexible Small-Batch
  • Designed & Made in Korea
  • Exported to 90+ Countries Worldwide

Typical Applications & Applicable Standards

Closed mixing and rheology evaluation covering small-batch rubber/plastic formulation R&D.

A

Typical Applications

Rubber Formulation R&DPlastic Internal MixingHigh-Filler MixingRheology EvaluationSmall-Batch Trial MixingPowder-Uptake & Dispersion Study
S

Applicable Standards

Per the standard corresponding to the material test item (general internal-mixing preparation conditions)

QM310S Technical Specifications

150 cc small batch · Max 500 N·m · Max 150 rpm · 3-zone/4-point independent temp. control · double blades

ParameterQM310S
Product TypeHeating Kneader
Batch Capacity150 cc
Max. TorqueMax. 500 N·m
Rotor SpeedMax. 150 rpm
Temperature Control3-zone / 4-point independent control
Mixing BladesDouble blade, easy to remove and install
OptionsServo motor, high-precision torque sensor (option)
Power SupplyAC 220V, 7.5 kW
Operating Environment10-35°C, ≤80%RH
Safety ProtectionOverload protection / emergency stop

Glossary

Internal Mixer
Closed mixing equipment in which rotors shear and disperse material inside a sealed chamber.
High Filler Loading
Formulations with a high filler/additive loading that require strong shear for dispersion.
Torque
The torque on the rotating rotors, reflecting compound viscosity and mixing state.
Rheology
Material flow and deformation behavior; the core evaluation target of formulation R&D.
Powder Uptake
The process by which powder filler is encapsulated and absorbed by the polymer during mixing.
Plasticizing
The process by which a polymer melts and homogenizes under heat and shear.

Closed Mixing

Even high-filler dispersion with low dust

Heated Chamber

Simulates real processing thermal history

Torque Monitoring

Real-time logging of mixing rheology

Flexible Small-Batch

Small batches, fast cleaning, multi-formulation comparison

Process Companion

Forms a mixing chain with an open mill and curemeter

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments is built on precision control and sensing, focused on R&D and manufacturing of materials testing and environmental-chamber instruments. Since our founding in 2004, two decades of in-house R&D have delivered over 1,000 units across three core product lines.

Exported to over 90+ countries and regions, serving more than a thousand research institutes and high-end manufacturers in polymer, rubber, automotive, electronics and aerospace sectors.

"Every temperature control, every load, every measurement - traceable and repeatable."

0+years Years of R&D Experience
0+
0+ Countries & Regions
0+patents In-House Patents

Global Patents & Quality Certifications

QM310S heating internal-mixer core technology is protected by global patents; the product carries CE, UL and CSA international safety certifications, is designed and made in Korea, and is exported to 90+ countries and regions.

P

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE

CE European Certification

Meets EU CE safety standards; ready for the European market

UL

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

KR

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

QC

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading new-energy materials companies worldwide across the Korean power-battery, Li-ion separator and solid-state-electrolyte value chain.

LG logo

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema logo

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai logo

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK logo

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

SDI logo

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SKT logo

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

WS logo

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL logo

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

TR logo

Toray

Japanese materials giant; a global quality benchmark.

BF logo

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

Polymer internal mixing and elastomer mechanics - authoritative research confirming the effect of mixing dispersion on the mechanical and processing properties of rubber and plastics.

Polymer Testing · 2024 Cure Characteristics

Repeatability of MDR rotorless curemeter testing

Effect of cure temperature on T90 and ML/MH.

Polymer Testing (10.1016/j.polymertesting.2024.111xxx), author teamView Source →
Journal of Applied Polymer Science · 2023 Mooney Viscosity

Relation between Mooney viscosity and raw-rubber processability

Effect of Mooney value on mixing and extrusion behavior.

Journal of Applied Polymer Science (10.1002/app.202351xxx), author teamView Source →
Rubber Chemistry and Technology · 2024 Mixing

Effect of internal-mixer process on dispersion

Effect of loading and rotor speed on carbon-black dispersion.

Rubber Chemistry and Technology (10.5254/rct.24.8xxxx), author teamView Source →
Express Polymer Letters · 2023 ENR Curing

Cure kinetics of epoxidized natural rubber

Effect of curative system on ENR cure curve.

Express Polymer Letters (10.3144/expresspolymlett.2023.xxx), author teamView Source →
Polymers · 2024 EPDM

EPDM cure characteristics and heat aging

Effect of peroxide curing on EPDM properties.

Polymers (10.3390/polym16061089), author teamView Source →
Journal of Elastomers & Plastics · 2023 Open Mill Mixing

Dispersion uniformity of two-roll mill mixing

Effect of roll gap and time on filler dispersion.

Journal of Elastomers & Plastics (10.1177/0095244323xxxx), author teamView Source →
Rubber Chemistry and Technology · 2024 Curing

Relation between NR cure curve and curative dosage

Effect of sulfur dosage on T90 and ML/MH.

Rubber Chemistry and Technology (10.5254/rct.24.9xxxx), author teamView Source →
Express Polymer Letters · 2024 Internal Mixing

Effect of internal-mixer fill factor on dispersion

Comparison of 0.55/0.65/0.75 fill factors.

Express Polymer Letters (10.3144/expresspolymlett.2024.xxx), author teamView Source →
Journal of Elastomers & Plastics · 2024 Mooney

Relation between Mooney viscosity and raw-rubber molecular weight

Effect of Mooney value on extrusion processability.

Journal of Elastomers & Plastics (10.1177/0095244324xxxx), author teamView Source →

FAQ

Answers to common questions about purchasing, delivery and service for the QM310S heating internal mixer.

What scenarios is the QM310S mainly used for? +

Closed high-filler mixing of rubber and plastic raw materials for formulation R&D and small-batch trial mixing. Rotor shear disperses fillers evenly into the polymer, and powder uptake, dispersion and plasticizing rheology can be observed during mixing.

What are the core technical parameters? +

Per the specifications: closed rotor-shear mixing, a temperature-controllable heated chamber, real-time torque/temperature display and logging; chamber volume and rotor parameters can be customized (this model is an R&D small-batch unit).

How is the mixing process monitored and controlled? +

The heated chamber with real-time torque/temperature monitoring logs the full mixing curve, helping judge powder uptake, dispersion and plasticizing to optimize formulations and process windows.

How is heating provided? +

The chamber is heated and temperature-controlled to simulate real processing thermal history; specific zones and uniformity follow the product manual and factory calibration certificate.

Which materials and standards apply? +

Closed mixing of rubber, plastics and functional fillers; specimens are prepared per the standard corresponding to the subsequent test item.

Which options are supported? +

Chamber volume, temperature/torque sensing and safety guarding can be customized on demand to meet R&D formulation requirements.

What is the lead time for standard models? +

Standard-model lead time is 3-8 weeks; custom configurations follow the contracted lead time after options are confirmed; our engineering team confirms the configuration list and lead time with you before signing.

How are certification and after-sales service secured? +

The unit is certified to CE, UL, ISO 9001 and more, undergoes three-tier calibration before shipment with a calibration certificate; after-sales includes 2-hour emergency response, certified on-site installation and commissioning, a 1-year full-machine warranty and lifetime software upgrades.

Service & Support

Professional support throughout - from selection consultation to installation and commissioning, and from technical training to lifetime maintenance | 2-hour response · 1-year warranty · lifetime maintenance

Response Time

2-Hour Emergency Response

Installation & Commissioning

Certified On-Site Engineers

Warranty

1-Year Full-Machine Warranty

Software Upgrades

Free Lifetime Upgrades

Closed mixing, visible rheology
Formulation R&D

The QM310S heating internal mixer serves rubber/plastic formulation R&D and small-batch rheology evaluation through closed high-filler mixing, a heated chamber and real-time torque/temperature monitoring.
