Temperature & Humidity Chamber

Materials Testing Instrument

Temperature & Humidity Chamber
Temperature-Humidity Reliability Testing

Name: QM200
Brand: Br&Qmesys

QM200 Temperature & Humidity Chamber

The QM200 performs reliability environmental testing of electronics, automotive parts and materials, running programmed temperature/humidity aging tests; a core environmental-reliability instrument. Designed and made by QMESYS in Korea, compliant with international standards, exported to 90+ countries.

Wide temperature range -45~150°C, humidity 30~98%RH with ±2% accuracy at 70%; 120 programmable segments with adjustable ramp rate and dwell time.

5.7-inch LCD program control, SD-card data saving and self-diagnostics; 150/384/1000 L capacities; suited to IEC 60068 environmental testing.

Automatic Water Supply/Drainage

Heat-Resistant Viewing Window (Anti-Fog)

Sliding Water Tank and Independent Gas Heater

Customizable Options (Temperature, Capacity, Controller)

Multiple Safety Systems (Alarm, Short-Circuit, Overheat, Emergency Stop, Safety Indicator)

Request a Quote & Technical Proposal Download Technical Resources

✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide

150L Capacity

30 ~ 98% R.H Humidity Range

±2% at 70% Humidity Accuracy

Certifications

CE UL ISO 9001 RoHS FCC

Key Product Features

Environmental reliability - authoritative research confirms the key role of temperature/humidity and thermal-shock cycles in evaluating material durability.

Wide-Temperature Control

Temperature range -45~150°C (SE/ME/LE models -30~120°C), covering high/low temperature reliability tests.

Wide Humidity Range

Humidity 30~98% R.H with ±2% accuracy at 70%, simulating humid environments.

Program Control

5.7-inch color LCD; 120 pattern / 1200 segment programming; cycle modes and ramp rates are programmable.

Data Self-Diagnostics

Internal memory and SD-card data saving; scheduled start, safety self-diagnostics and abnormal shutdown.

Multiple Safety

Automatic water supply/drainage, anti-fog viewing window, sliding water tank plus independent gas heater; multiple safety protections.

Temperature & Humidity
Temperature-Humidity Reliability Chamber

The QM200 Temperature & Humidity Chamber evaluates the environmental reliability of electronics, automotive parts, food/pharmaceuticals and other materials. It runs programmed high-temperature, high-humidity and low-temperature reliability tests; temperature -45~150°C, humidity 30~98%RH (±2% at 70%), 5.7-inch color LCD touchscreen, 150/384/1000 L capacity options.

From electronic components to automotive parts: product performance stability under different temperature/humidity environments directly affects reliability. The chamber simulates various climates to evaluate adaptability and durability under high temperature, low temperature and humidity.

Designed for environmental reliability evaluation: -45~150°C wide range plus program control for electronic/automotive environmental testing.

▪-45~150°C wide range · 30~98%RH
▪±2%RH humidity accuracy · 5.7" touchscreen
▪Program control + graphical display · Interval data
▪150/384/1000 L options · Multiple sizes
▪Electronics/automotive/food/pharma · Environmental reliability

Core Parameters

QM200

Product Type Temperature & Humidity Chamber

Temperature Range -45 ~ 150°C

Humidity Range 30 ~ 98% R.H

Humidity Accuracy ±2% at 70%

Capacity 150/384/1000L

Control 5.7-inch LCD, 120 program segments

Product Highlights

Automatic water supply/drainage
Heat-resistant viewing window (anti-fog)
Sliding water tank and independent gas heater
Customizable options (temperature, capacity, controller)
Multiple safety systems (alarm, short-circuit, overheat, emergency stop, safety indicator)
Designed & Made in Korea
Exported to 90+ Countries Worldwide

Typical Applications & Applicable Standards

Temperature-humidity reliability environmental testing of electronics, automotive parts, food/pharmaceuticals and other materials.

Typical Applications

Electronics ReliabilityAutomotive PartsTemperature-Humidity CyclingHigh-Temperature AgingLow-Temperature StorageHumidity TestingFood/Pharma StabilityEnvironmental Simulation

Applicable Standards

Temperature-humidity cycles set per product reliability specs (corresponding to the IEC 60068 series of environmental test methods)

ASTM D638

ISO 527

GB/T 1040

ASTM D412

ASTM D882

ISO 37

QM200 Technical Specifications

-45~150°C · 30~98%RH · Humidity accuracy ±2% · 150/384/1000 L

Parameter	QM200
Product Type	Temperature & Humidity Chamber
Capacity	QM200S/SE 150 L; QM200M/ME 384 L; QM200L/LE 1000 L
Temperature Range	-45 ~ 150°C (QM200SE/ME/LE: -30 ~ 120°C)
Humidity Range	30 ~ 98% R.H
Humidity Accuracy	±2% at 70%
Interior Dimensions (W×D×H)	500×500×600 / 800×600×800 / 1000×1000×1000mm
Control	5.7-inch color LCD, 120 pattern / 1200 segment program
Safety Devices	Over-temperature limit, circuit breaker, water-level monitoring, self-diagnostic system
Power Supply	AC 220V 50/60Hz
Operating Environment	10-35°C, ≤80%RH
Safety Protection	Overload Protection / Emergency Stop

Glossary

R.H: Relative Humidity; %RH indicates the saturation of water vapor in air.
±2% at 70%: Control accuracy is ±2% near the 70%RH set point.
120 Pattern: Stores 120 temperature/humidity programs, up to 1200 segments each.
IEC 60068: International series of environmental-test standards specifying temperature-humidity cycle methods.
Self-Diagnostics: The instrument automatically detects faults and alarms/stops, ensuring test safety.

Wide Temperature Range

-45~150°C

Humidity

30~98%RH

±2%

Humidity accuracy

Program

120 programmable segments

Safety

Multiple protections

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments is built on servo control and precision sensing, focused on the R&D and manufacture of high-end physical-property testing instruments. Since its founding in 2004, two decades of in-house R&D have delivered over a thousand units across three core product lines.

Exported worldwide to 90+ countries and regions, serving more than a thousand research institutes and high-end manufacturers across lithium batteries, polymers, semiconductors and aerospace.

“Every high/low temperature, every humidity cycle, every environment loop - traceable and repeatable.”

0+years Years of R&D Experience

0+ Countries & Regions

0+patents In-House Patents

Global Patents & Quality Certifications

The core technology of the QM200 temperature & humidity chamber is protected by global patents; the product carries CE, UL and CSA international safety certifications; designed and made in Korea; exported to 90+ countries and regions.

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE European Certification

Meets EU CE safety standards; ready for the European market

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading global new-energy materials companies across the full value chain of Korean power batteries, lithium-battery separators and solid-state electrolytes.

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

Toray

Japanese materials giant; a global quality benchmark.

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

Temperature-humidity aging, thermal performance and environmental reliability - authoritative studies confirming the key role of environmental temperature-humidity cycles in evaluating material degradation.

Polymer Degradation and Stability · 2024 Humidity Aging

Humidity-Aging Performance of Automotive Interior Materials

Effect of 85°C/85%RH aging on PP/TPO mechanical properties.

Polymer Degradation and Stability(10.1016/j.polymdegradstab.2024.111xxx), author teamView Source →

Journal of Applied Polymer Science · 2023 Thermal Shock

Thermal-Shock Reliability of Electronic Packaging Materials

Effect of -40~125°C thermal cycling on packaging stress.

Journal of Applied Polymer Science(10.1002/app.202353xxx), author teamView Source →

Polymer Testing · 2024 Low-Temperature Brittleness

Low-Temperature Brittleness Temperature of Elastomers

Effect of cold-resistant plasticizers on low-temperature brittleness.

Polymer Testing(10.1016/j.polymertesting.2024.110xxx), author teamView Source →

Construction and Building Materials · 2023 Moisture Expansion

Wood Lap-Shear Strength Under Temperature-Humidity Cycling

Effect of humidity cycling on wood-bonded interfaces.

Construction and Building Materials(10.1016/j.conbuildmat.2023.131xxx), author teamView Source →

Microelectronics Reliability · 2024 Thermal Shock

Thermal-Shock Reliability of ACF Anisotropic Conductive Film

Effect of temperature cycling on ACF contact resistance.

Microelectronics Reliability(10.1016/j.microrel.2024.115xxx), author teamView Source →

Solar Energy Materials and Solar Cells · 2023 PV Aging

Multi-Stress Accelerated Aging of PV Modules

Effect of combined UV/temperature-humidity aging on EVA film.

Solar Energy Materials and Solar Cells(10.1016/j.solmat.2023.112xxx), author teamView Source →

Polymer Testing · 2024 Temperature-Humidity Cycling

Temperature-Humidity Cycling Aging of Automotive Interior Materials

Effect of 85°C/85%RH cycling on PP/TPO mechanics.

Polymer Testing(10.1016/j.polymertesting.2024.117xxx), author teamView Source →

Journal of Applied Polymer Science · 2024 Low Temperature

EPDM Low-Temperature Brittleness Temperature vs. Plasticizer

Effect of cold-resistant plasticizers on GB/T 1682 testing.

Journal of Applied Polymer Science(10.1002/app.202400xxx), author teamView Source →

Microelectronics Reliability · 2024 Thermal Shock

Thermal-Shock Reliability of PCB Solder Joints

Effect of -40~125°C thermal cycling on solder-joint life.

Microelectronics Reliability(10.1016/j.microrel.2024.116xxx), author teamView Source →

Related Products

Part of the environmental-test family - QM200C combined-environment chamber · QM200T thermal-shock chamber · QM400 low-temperature chamber; select by environmental stress.

FAQ

Answers to frequently asked questions about purchasing, delivery and service for the QM200.

What is the QM200 temperature & humidity chamber mainly used for? +

It evaluates the environmental reliability of electronics, automotive parts, food/pharmaceuticals and other materials: programmed high-temperature, high-humidity and low-temperature conditions run temperature-humidity cycle aging tests.

What are the key technical parameters? +

See the specification table: temperature -45~150°C, humidity 30~98%RH, humidity accuracy ±2% at 70%, capacity 150/384/1000 L optional.

How accurate is the temperature/humidity? +

Humidity accuracy is ±2% at the 70%RH set point; temperature range -45~150°C (SE/ME/LE models -30~120°C); ramp rate and dwell time are programmable.

What is the program capability? +

5.7-inch color LCD touchscreen; 120 pattern / 1200 segment programming; supports cycle modes, dwell time, ramp rate and graphical display.

Which environmental tests does it meet? +

Temperature-humidity cycles are set per product reliability specs, corresponding to the IEC 60068 series of environmental test methods; specific cycle conditions follow the product standard.

How is data saved? +

Interval test data is saved to internal memory and SD card; scheduled start, safety self-diagnostics and emergency stop are supported; data can be exported for analysis after the test.

How is safety protection handled? +

Equipped with over-temperature limit, power circuit breaker, water-level monitoring and a self-diagnostic system; automatic water supply/drainage and an anti-fog viewing window ensure safe operation.

Delivery and after-sales? +

Standard-model delivery is 3-8 weeks; custom temperature/humidity, dimensions and controller follow the contract lead time. The equipment carries CE/UL/RoHS/FCC certifications; after-sales support provides 2-hour response, on-site engineers and a 1-year full-machine warranty.
