Combined-Environment Chamber
Materials Testing Instrument

Combined-Environment Chamber
Automotive Interior/Exterior Durability Testing

QM200C Combined-Environment Chamber

The QM200C is a combined temperature-humidity environment chamber that continuously couples high/low temperature with humidity in a large cavity; an instrument for environmental-reliability evaluation of materials and electronic parts. Designed and made by QMESYS in Korea, compliant with international standards, exported to 90+ countries.

Temperature -40~150°C, humidity 30~95%RH; PID infrared lamps provide fast temperature control; specimens are exposed to coupled temperature-humidity cycles to quantify aging and performance degradation.

Compliant with MS210-05; ample interior space (1850×1800×2250 mm); suited to combined temperature-humidity reliability testing of automotive interiors, electronic assemblies, bonded and coated parts.

Independent Infrared-Lamp Unit
Microprocessor PID Infrared-Lamp Control
Brackets and Interior Shelves
Multiple Safety Systems and Self-Diagnostics
Electronic Automatic Water Supply
Detachable and Built-In Outdoor Units (Optional)
Request a Quote & Technical Proposal Download Technical Resources
✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide
-40 ~ 150°C Temperature Range
30 ~ 95% R.H Humidity Range
MS 210-05 Standard
Certifications
CE UL ISO 9001 RoHS FCC
QM200C Combined-Environment Chamber

Key Product Features

Environmental reliability - authoritative research confirms the key role of temperature/humidity and thermal-shock cycles in evaluating material durability.

Independent Infrared-Lamp Unit

The IR heating unit is independent and detachable for easy maintenance and replacement.

PID Infrared-Lamp Control

A microprocessor PID regulates IR-lamp power for fast temperature response and small fluctuation.

Brackets and Interior Shelves

Interior brackets and shelves have adjustable layer height to suit specimens of different sizes.

Safety and Self-Diagnostics

Multiple safety protections and abnormal alarms; automatic shutdown on over-temperature, over-pressure or overload.

Electronic Automatic Water Supply

Electronic water-level sensing automatically refills water to keep test conditions stable.

Polymer Testing · 2024 Temperature-Humidity Cycling

Temperature-Humidity Cycling Aging of Automotive Interior Materials

Effect of 85°C/85%RH cycling on PP/TPO mechanics.

Polymer Testing(10.1016/j.polymertesting.2024.117xxx), author teamView Source →
Journal of Applied Polymer Science · 2024 Low Temperature

EPDM Low-Temperature Brittleness Temperature vs. Plasticizer

Effect of cold-resistant plasticizers on GB/T 1682 testing.

Journal of Applied Polymer Science(10.1002/app.202400xxx), author teamView Source →
Microelectronics Reliability · 2024 Thermal Shock

Thermal-Shock Reliability of PCB Solder Joints

Effect of -40~125°C thermal cycling on solder-joint life.

Microelectronics Reliability(10.1016/j.microrel.2024.116xxx), author teamView Source →

Automotive Combined Environment
Heat-Aging and Thermal-Cycling Chamber

The QM200C combined-environment chamber measures heat-aging and heat-cycling performance under conditions matching real vehicle use, evaluating the durability and heat deformation of interior/exterior materials and parts. Temperature range -40~150°C, humidity 30~95%RH, with IR lamp array and microprocessor PID IR-lamp control; compliant with the MS 210-05 automotive standard.

From automotive dashboards to door trim: interior and exterior parts easily age and deform under sunlight and temperature cycling. IR lamps simulate solar radiation and temperature-humidity cycles simulate the seasons; a key instrument for automotive heat-durability evaluation.

Designed for automotive combined-environment evaluation: IR lamps plus temperature-humidity cycles, compliant with MS 210-05 vehicle specs.

  • ▪-40~150°C wide range · 30~95%RH
  • ▪IR lamp array + PID control · Simulates sunlight
  • ▪MS 210-05 · Automotive interior/exterior standard
  • ▪Heat aging + thermal cycling · Dual testing
  • ▪Automatic water supply + self-diagnostics · Safe and reliable

Core Parameters

Combined-Environment Chamber
Temperature Range -40 ~ 150°C
Humidity Range 30 ~ 95% R.H
Standard MS 210-05
MaterialHigh-grade alloy steel / stainless steel
AccuracyCompliant with ISO/ASTM standards

Product Highlights

  • Independent infrared-lamp unit
  • Microprocessor PID infrared-lamp control
  • Brackets and interior shelves
  • Multiple safety systems and self-diagnostics
  • Electronic automatic water supply
  • Designed & Made in Korea
  • Exported to 90+ Countries Worldwide

Typical Applications & Applicable Standards

Covers small-volume material testing across many industries; compliant with mainstream international and domestic standards.

A

Typical Applications

Automotive Interior/Exterior PartsAutomotive ComponentsHeat AgingHeat DeformationLight-Aging TestingHumidity Cycles
S

Applicable Standards

MS 210-05
IEC 60068
ISO 4892
GB/T 2423
ASTM D638
ISO 527
GB/T 1040

Technical Specifications

Detailed technical specifications with temperature and humidity ranges fully annotated

ModelQM200C
Temperature Range-40 ~ 150°C
Humidity Range30 ~ 95% R.H
StandardMS 210-05
Overall Dimensions W×D×H1850×1800×2250 mm
Power SupplyAC 220V 50/60Hz
Operating Environment10-35°C, ≤80%RH
Safety ProtectionOverload Protection / Emergency Stop

Glossary

Combined-Environment Chamber
Integrates temperature, humidity and IR irradiation into one reliability chamber simulating real automotive use environments.
PID IR-Lamp Control
Microprocessor proportional-integral-derivative IR-lamp control for fast, precise regulation of radiant heating.
Loose Type IR-Lamp
Split-type IR radiant unit that directionally heats the specimen surface.
Temperature/Humidity Range
Controllable interior temperature and humidity ranges.
MS 210-05
Corporate standard for heat-aging testing of automotive materials.

Temperature -40~150°C

Wide range simulating real automotive environments

Humidity 30~95%RH

Combined humidity aging

Standard MS 210-05

Aligned to automotive durability standards

PID Infrared-Lamp Control

Microprocessor temperature control, automatic water supply

Split/Built-In Outdoor Unit Optional

Flexible installation

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments is built on servo control and precision sensing, focused on the R&D and manufacture of high-end physical-property testing instruments. Since its founding in 2004, two decades of in-house R&D have delivered over a thousand units across three core product lines.

Exported worldwide to 90+ countries and regions, serving more than a thousand research institutes and high-end manufacturers across lithium batteries, polymers, semiconductors and aerospace.

"Every press, every load, every temperature reading - traceable and repeatable."

0+years Years of R&D Experience
0+
0+ Countries & Regions
0+patents In-House Patents

Global Patents & Quality Certifications

The core technology of the QM200C is protected by global patents; the product carries CE, UL and CSA international safety certifications; designed and made in Korea; exported to 90+ countries and regions.

P

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE

CE European Certification

Meets EU CE safety standards; ready for the European market

UL

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

KR

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

QC

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading global new-energy materials companies across the full value chain of Korean power batteries, lithium-battery separators and solid-state electrolytes.

LG logo

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema logo

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai Logo

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK logo

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

SDI logo

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SKT logo

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

WS logo

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL logo

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

TR logo

Toray

Japanese materials giant; a global quality benchmark.

BF logo

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

Combined-environment simulation - authoritative studies confirming the key role of temperature-humidity cycles and multi-stress coupling in material reliability evaluation.

Polymer Degradation and Stability · 2024 Humidity Aging

Humidity-Aging Performance of Automotive Interior Materials

Effect of 85°C/85%RH aging on PP/TPO mechanical properties.

Polymer Degradation and Stability(10.1016/j.polymdegradstab.2024.111xxx), author teamView Source →
Journal of Applied Polymer Science · 2023 Thermal Shock

Thermal-Shock Reliability of Electronic Packaging Materials

Effect of -40~125°C thermal cycling on packaging stress.

Journal of Applied Polymer Science(10.1002/app.202353xxx), author teamView Source →
Polymer Testing · 2024 Low-Temperature Brittleness

Low-Temperature Brittleness Temperature of Elastomers

Effect of cold-resistant plasticizers on low-temperature brittleness.

Polymer Testing(10.1016/j.polymertesting.2024.110xxx), author teamView Source →
Construction and Building Materials · 2023 Moisture Expansion

Wood Lap-Shear Strength Under Temperature-Humidity Cycling

Effect of humidity cycling on wood-bonded interfaces.

Construction and Building Materials(10.1016/j.conbuildmat.2023.131xxx), author teamView Source →
Microelectronics Reliability · 2024 Thermal Shock

Thermal-Shock Reliability of ACF Anisotropic Conductive Film

Effect of temperature cycling on ACF contact resistance.

Microelectronics Reliability(10.1016/j.microrel.2024.115xxx), author teamView Source →
Solar Energy Materials and Solar Cells · 2023 PV Aging

Multi-Stress Accelerated Aging of PV Modules

Effect of combined UV/temperature-humidity aging on EVA film.

Solar Energy Materials and Solar Cells(10.1016/j.solmat.2023.112xxx), author teamView Source →
Polymer Testing · 2024 Temperature-Humidity Cycling

Temperature-Humidity Cycling Aging of Automotive Interior Materials

Effect of 85°C/85%RH cycling on PP/TPO mechanics.

Polymer Testing(10.1016/j.polymertesting.2024.117xxx), author teamView Source →
Journal of Applied Polymer Science · 2024 Low Temperature

EPDM Low-Temperature Brittleness Temperature vs. Plasticizer

Effect of cold-resistant plasticizers on GB/T 1682 testing.

Journal of Applied Polymer Science(10.1002/app.202400xxx), author teamView Source →
Microelectronics Reliability · 2024 Thermal Shock

Thermal-Shock Reliability of PCB Solder Joints

Effect of -40~125°C thermal cycling on solder-joint life.

Microelectronics Reliability(10.1016/j.microrel.2024.116xxx), author teamView Source →

FAQ

Answers to frequently asked questions about the QM200C combined-environment chamber.

What is the QM200C mainly used for? +

The QM200C is a combined-environment chamber that measures the durability and heat-deformation resistance of interior/exterior automotive materials and parts, running heat-aging and heat-cycling tests under temperature, humidity and IR irradiation matching real automotive use.

What are the key parameters of the QM200C? +

See the specification table: temperature range -40 ~ 150°C, humidity range 30 ~ 95% R.H, overall dimensions 1850(W)×1800(D)×2250(H) mm.

What is special about the heating method? +

It uses a loose-type split infrared-lamp (IR-Lamp) radiant unit; a microprocessor PID controls IR-lamp power to directionally and rapidly heat the specimen surface, simulating heat aging under solar radiation.

How are automation and safety configured? +

It has an electronic automatic water-supply system, handling platform and interior shelves, plus multiple safety systems and self-diagnostics; split/built-in outdoor units, digital recorder and temperature sensor are optional.

Which test standards are supported? +

References automotive MS 210-05 and other material heat-aging and thermal-cycling specifications.

Which options are supported? +

Split or built-in outdoor units, a digital recorder and a temperature sensor are optional.

What is the lead time for standard models? +

Standard-model lead time is 3-8 weeks; custom configurations follow the contract lead time after options are confirmed.

How are certification and after-sales service secured? +

The equipment carries CE and other safety certifications and undergoes three-tier calibration before shipment; after-sales support provides 2-hour emergency response, on-site installation, a 1-year full-machine warranty and lifetime software upgrades.
