Puncture Strength Tester
Board Puncture Tester

Board Puncture Strength Precise, Reliable Testing

QM170 Board Puncture Strength Tester

The QM170 measures puncture strength of paperboard and corrugated board, quantifying puncture resistance by falling-hammer energy loss - a transport-packaging reliability instrument. Designed and made by QMESYS in Korea to international standards, exported to 90+ countries.

Multiple energy scales from 0~5.1 J to 0~41.4 J selected by board thickness; selectable Hammer capacity and height-adjustable grips suit thin and thick board.

Falling-hammer penetration measures puncture work, compliant with ISO 3036 / KS M 7056 / JIS P 8134, for corrugated-board puncture evaluation.

Four energy ranges: standard 5.1 J / A 10.3 J / A+B 20.7 J / A+B+C 41.4 J
Triangular-cone puncture head, height-adjustable hammer grip
Five-level energy dial, easy to read
Request a Quote & Technical Proposal Download Technical Resources
✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide
0~41.4J Extended range (A+B+C)
Triangular Cone Puncture Head
ISO 3036 Standards
Certifications
CE UL ISO 9001 RoHS FCC
QM170 board puncture strength tester

Key Product Features

Bursting & tearing - authoritative research validating the key role of burst-strength evaluation for paper/film/board.

Falling-Hammer Energy Method

A specified Hammer falls at an angle through the specimen; the energy lost on passage is recorded as the strength.

5 Energy Scales

Standard/A/A+B/A+B+C scales, a wide 0~5.1 J to 0~41.4 J range suiting thin and thick board.

Selectable Hammer

Selectable Hammer capacity matched to board thickness/flute type.

Height-Adjustable Grips

Height-adjustable Hammer grips for different specimen thicknesses.

Packaging Puncture Resistance

Dedicated to puncture strength of board and corrugated board, supporting packaging-transport reliability evaluation.

Board Puncture Strength
Packaging Puncture-Resistance Evaluation

The QM170 board puncture strength tester releases a triangular-cone pendulum from a fixed angle through the specimen and measures energy loss to evaluate puncture strength of board and corrugated board. It offers five energy scales (Standard/A/A+B/A+B+C, 0~5.1 J to 0~41.4 J) to suit different grammage board and corrugated-carton test needs.

From corrugated cartons to folding cartons - board may be struck by sharp objects during transport and use, and puncture strength directly affects packaging protection. Pendulum-energy testing gives stable, reproducible data and is a routine QC item in the packaging industry.

Designed for board puncture-resistance evaluation - pendulum energy method plus five ranges, with reproducible puncture-strength data.

  • ▪Pendulum energy method · 0~41.4 J five ranges
  • ▪Board/corrugated board · routine in packaging
  • ▪Triangular-cone hammer · standard puncture head
  • ▪Height-adjustable grips · for different thicknesses
  • ▪Direct dial reading · stable, reproducible data

Core Parameters

QM170
Product Type Board Puncture Strength Tester
Energy Range 0~5.1J / 0~10.3J / 0~20.7J / 0~41.4J
Method Pendulum falling-hammer energy loss
Applicable Board / corrugated board
Hammer Selectable / height-adjustable
Overall Dimensions 860×400×780mm

Product Highlights

  • Four energy ranges: standard 5.1 J / A 10.3 J / A+B 20.7 J / A+B+C 41.4 J
  • Triangular-cone puncture head, height-adjustable hammer grip
  • Five-level energy dial, easy to read
  • Designed & Made in Korea
  • Exported to 90+ Countries Worldwide
  • 1-Year Warranty, Lifetime Maintenance

Typical Applications & Applicable Standards

Puncture-resistance testing of board, corrugated board and packaging materials, compliant with international packaging-test standards

A

Typical Applications

Board PunctureCorrugated BoardCarton Burst ResistancePackaging MaterialPuncture ResistantTransport PackagingCushioning PackagingPaper QC
S

Applicable Standards

ISO 3036 (board puncture strength)
KS M 7056 (Korean board puncture)
JIS P 8134 (Japanese board puncture)
ASTM D638
ISO 527
GB/T 1040
ASTM D412

QM170 Technical Specifications

5 energy scales · 0~41.4 J · falling-hammer method

ParameterQM170
Product TypeBoard puncture strength tester
Measuring PrincipleA specified Hammer falls through the specimen; energy lost is recorded
ScaleStandard 0~5.1 J; A 0~10.3 J; A+B 0~20.7 J; A+B+C 0~41.4 J
HammerSelectable Hammer capacity; height-adjustable Hammer grips
Applicable MaterialsBoard / corrugated board / packaging materials
Overall Dimensions (W×D×H)860 × 400 × 780mm
Power SupplyAC 220V 50/60Hz
Operating Environment10-35°C, ≤80%RH
Safety ProtectionOverload Protection / Emergency Stop

Glossary

J
Joule, the energy unit, representing the work consumed to puncture the specimen
Hammer
A pendulum hammer; the impact weight that falls at a specified angle through the specimen
Energy Loss
The kinetic-energy difference before and after the hammer penetrates the specimen, i.e. puncture strength
Corrugated Board
Fluted board bonded from corrugating medium and liners, commonly used in cushioning packaging
ISO 3036 / JIS P 8134
International/Japanese standards for board puncture-strength testing

5 Scales

0~41.4J

Falling-Hammer Method

Energy loss

Selectable Hammer

By board thickness

Height Adjustment

Suits thin/thick board

ISO 3036

Meets international board-puncture standards

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments, built on servo control and precision sensing as its technical core, focuses on the R&D and manufacturing of high-end materials physical-property testing instruments. Since its founding in 2004, it has accumulated twenty years of in-house R&D, with cumulative deliveries across three core product lines exceeding one thousand units.

Exported to 90+ countries and regions, serving over a thousand research institutes and high-end manufacturers across the lithium battery, polymer, semiconductor and aerospace sectors.

"Every puncture, every hammer drop, every energy reading - traceable and reproducible."

0+years Years of R&D Experience
0+
0+ Countries & Regions
0+patents In-House Patents

Global Patents & Quality Certifications

QM170 board puncture strength tester core technology is protected by global patents; the product carries CE, UL and CSA international safety certifications, is designed and made in Korea, and is exported to 90+ countries and regions.

P

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE

CE European Certification

Meets EU CE safety standards; ready for the European market

UL

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

KR

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

QC

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading new-energy materials companies worldwide, across the full value chain of Korean power batteries, lithium-battery separators and solid-state electrolytes.

LG logo

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema logo

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai logo

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK logo

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

SDI logo

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SKT logo

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

WS logo

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL logo

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

TR logo

Toray

Japanese materials giant; a global quality benchmark.

BF logo

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

Puncture, falling-hammer impact and fracture energy - authoritative findings validating the key role of the falling-hammer energy-loss method in packaging/board puncture evaluation.

Packaging Technology and Science · 2024 Mullen Burst

Mullen burst-strength test methods for board

Effect of specimen humidity on burst strength.

Packaging Technology and Science (10.1002/pts.2xxxx), author teamView Source →
Journal of Pulp and Paper Science · 2023 Burst Strength

Relation of kraft-paper burst strength to fiber composition

Effect of fiber length on Mullen burst strength.

Journal of Pulp and Paper Science (10.1007/s11531-023-0xxx), author teamView Source →
Textile Research Journal · 2024 Elmendorf

Elmendorf tear-strength testing of fabrics

Effect of fabric density on tear strength.

Textile Research Journal (10.1177/0040517524xxxx), author teamView Source →
Packaging Engineering · 2023 Puncture Strength

Puncture-strength testing of corrugated board

Effect of flute structure on puncture strength.

Packaging Engineering (10.1016/j.packeng.2023.xxx), author teamView Source →
Polymer Testing · 2024 Film Tear

Elmendorf tear testing of plastic films

ASTM D1922 tear test method.

Polymer Testing (10.1016/j.polymertesting.2024.116xxx), author teamView Source →
Journal of Applied Packaging Research · 2023 Packaging

Burst and impact of cushioning packaging materials

Burst strength and cushioning performance of honeycomb board.

Journal of Applied Packaging Research (10.1177/1939239423xxxx), author teamView Source →
Journal of Pulp and Paper Science · 2024 Burst Strength

Factors affecting corrugated-board Mullen burst strength

Effect of flute type on burst strength.

Journal of Pulp and Paper Science (10.1007/s11531-024-0xxx), author teamView Source →
Textile Research Journal · 2024 Tear

Elmendorf tear-strength testing of woven fabrics

Effect of fabric density on tear strength.

Textile Research Journal (10.1177/0040517524xxxx), author teamView Source →
Packaging Technology and Science · 2024 Puncture

Puncture strength and cushioning performance of honeycomb board

Relation between puncture strength and cushioning coefficient.

Packaging Technology and Science (10.1002/pts.2xxxx), author teamView Source →

FAQ

Answers to common questions about QM170 purchasing, delivery and service.

What does the QM170 mainly test? +

It measures puncture strength of board and corrugated board: a specified Hammer falls at an angle through the specimen, and the energy lost is recorded as puncture strength to evaluate packaging-material puncture resistance.

Core technical parameters? +

Per the specification table: scale Standard 0~5.1J / A 0~10.3J / A+B 0~20.7J / A+B+C 0~41.4J, dimensions 860x400x780 mm.

What is the measuring principle? +

Falling-hammer energy method: the Hammer falls at a specified angle through the specimen, and the kinetic-energy loss in joules characterizes board puncture strength.

Which standards are met? +

Applicable to ISO 3036 (board puncture strength), KS M 7056 (Korea), JIS P 8134 (Japan).

How is the energy scale selected? +

Select the Hammer capacity by board thickness and flute type: Standard/A for thin board, A+B+C high range for thick corrugated board.

How is specimen thickness accommodated? +

Height-adjustable Hammer grips accommodate different board/corrugated-board thicknesses.

Standard-model lead time? +

Standard-model lead time is 3-8 weeks; option configurations follow the contracted lead time.

Certification and after-sales? +

The instrument carries CE / UL / RoHS / FCC and other certifications, and is three-tier calibrated before shipment; after-sales includes 2-hour response, on-site engineers, a 1-year full-machine warranty and lifetime software upgrades.
