Extrusion Molding Machine
Materials Testing Instrument

Polymer Melt Extrusion Precision You Can Rely On

Laboratory Small-Scale Polymer Melt Extrusion

The QM1201 melts and extrudes plastic and rubber polymer specimens, heating the material and injecting it into molds to make standard specimens; an R&D sample-preparation instrument. Designed and made by QMESYS in Korea, compliant with international standards, exported to 90+ countries.

Heating temperature and pressing time are adjustable from RT to 300°C; the pneumatic extrusion cylinder delivers stable pressure; the 125 cc melt capacity suits small lab batches.

Interchangeable specimen molds produce bars, sheets and dumbbell specimens; small-batch extrusion up to 300 cc; an optional safety door protects high-temperature operation.

Pneumatic Extrusion Cylinder
Exchangeable Sample Frame
Adjustable Heating Temperature and Pressing Time
For Small-Batch Polymer Extrusion (200 cc)
Safety Door (Optional)
Request a Quote & Technical Proposal Download Technical Resources
✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide
RT~300°C Temperature Range
200cc Melt Capacity
Max.125mm Stroke
Certifications
CE UL ISO 9001 RoHS FCC
QM1201 Polymer Compounder

Key Product Features

Coating and extrusion - authoritative research confirms the key role of coating/extrusion in evaluating film forming.

Melt Extrusion Molding

Plastic and rubber are heated to melt and injected into the required mold or cavity to form specimens of a given shape.

Pneumatic Extrusion Cylinder

A pneumatic extrusion cylinder gives stable pressure; small-batch extrusion up to 300 cc suits R&D trials.

Temperature/Time Controllable

Heating temperature and pressing time are adjustable; RT~300°C covers common resin processing windows.

Interchangeable Molds

Specimen molds can be exchanged to flexibly switch between bars, sheets and dumbbell specimens.

Optional Safety Door

An optional Safety Door protects high-temperature melt-extrusion operation.

Polymer Melt Extrusion
Laboratory Small-Scale Sample Molder

The QM1201 polymer specimen tester heats and melts plastic and rubber and injects it into molds to make standard specimens. Driven by a pneumatic extrusion cylinder with interchangeable molds and adjustable heating temperature and pressing time; melt capacity 125 cc (max. extrusion 300 cc), temperature RT~300°C, stroke up to 250 mm, platen size 180×180 mm.

From formulation R&D to standard specimens: new-material R&D requires melting and pressing small amounts of polymer into standard specimens for mechanical testing. A small extruder uses little material, changes color easily, and controls temperature and pressure; it is a dedicated instrument for polymer-lab formulation screening and sample preparation.

Designed for polymer sample preparation: melt extrusion plus mold exchange for small laboratory specimens.

  • ▪RT~300°C heating · 125 cc melt capacity
  • ▪Pneumatic extrusion cylinder · 250 mm stroke
  • ▪Adjustable temperature/pressing time · Precise
  • ▪Interchangeable molds · Multiple specimen shapes
  • ▪Plastic/rubber formulation R&D · Small sample prep

Core Parameters

QM1201
Product Type Polymer Sample Tester
Temperature Range RT ~ 300°C
Melt Capacity 125cc
Stroke Max. 250mm
Platen Size 180×180mm
Overall Dimensions 850×850×1680mm

Product Highlights

  • Pneumatic extrusion cylinder
  • Exchangeable sample frame
  • Adjustable heating temperature and pressing time
  • For small-batch polymer extrusion (200 cc)
  • Safety door (optional)
  • Designed & Made in Korea
  • Exported to 90+ Countries Worldwide

Typical Applications & Applicable Standards

Covers plastic/rubber polymer specimen preparation and melt-extrusion molding; samples are prepared to the standard corresponding to the test item.

A

Typical Applications

Plastic SpecimensRubber SpecimensMelt ExtrusionBar PreparationSheet MoldingSmall-Batch SpecimensFormulation TrialsDumbbell Specimens
S

Applicable Standards

Prepared to the standard corresponding to the test item (e.g., ISO 527-2 / ASTM D 638 tensile bars)
ASTM D638
GB/T 1040
ASTM D412
ASTM D882
ISO 37

QM1201 Technical Specifications

RT~300°C temperature control · 125 cc melt · Stroke up to 250 mm · Interchangeable molds

ParameterQM1201
Product TypePolymer Sample Tester
Temperature RangeRT ~ 300°C
Melt Capacity125 cc (small-batch polymer extrusion up to 300 cc)
StrokeMax. 250mm
Platen Size180 × 180mm
Extrusion MethodPneumatic extrusion cylinder; interchangeable specimen molds
Overall Dimensions (W×D×H)850 × 850 × 1680mm
Power SupplyAC 220V 50/60Hz
Operating Environment10-35°C, ≤80%RH
Safety ProtectionOverload Protection / Emergency Stop

Glossary

Melt Extrusion
After heating and melting, compressed air injects the material into a mold to form the specimen.
cc
Volume unit; the 125 cc single-batch melt-chamber capacity.
RT
Room Temperature; the temperature range starts from ambient.
Mold Exchange
Changing the cavity mold prepares standard specimens of different shapes.
ISO 527-2 / ASTM D 638
Geometric standard for tensile specimens; the prepared bar is used for tensile testing.

RT~300°C

Covers common resins

Pneumatic Extrusion

Stable pressure

Exchangeable Mold

Multiple specimen shapes

Small-Batch Extrusion

300 cc, R&D-friendly

Temperature-Control Accuracy

±1°C precise control, stable heating

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments is built on servo control and precision sensing, focused on the R&D and manufacture of high-end physical-property testing instruments. Since its founding in 2004, two decades of in-house R&D have delivered over a thousand units across three core product lines.

Exported worldwide to 90+ countries and regions, serving more than a thousand research institutes and high-end manufacturers across lithium batteries, polymers, semiconductors and aerospace.

“Every melt, every extrusion, every specimen - traceable and repeatable.”

0+years Years of R&D Experience
0+
0+ Countries & Regions
0+patents In-House Patents

Global Patents & Quality Certifications

The core technology of the QM1201 polymer sample tester is protected by global patents; the product carries CE, UL and CSA international safety certifications; designed and made in Korea; exported to 90+ countries and regions.

P

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE

CE European Certification

Meets EU CE safety standards; ready for the European market

UL

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

KR

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

QC

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading global new-energy materials companies across the full value chain of Korean power batteries, lithium-battery separators and solid-state electrolytes.

LG logo

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema logo

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai Logo

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK logo

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

SDI logo

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SKT logo

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

WS logo

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL logo

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

TR logo

Toray

Japanese materials giant; a global quality benchmark.

BF logo

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

Specimen preparation, standard geometry and cutting - authoritative studies confirming the decisive role of consistent specimen preparation in mechanical test results.

Progress in Organic Coatings · 2024 Coating

Process-Parameter Optimization of a Laboratory Coater

Effect of coating speed and wet-film thickness on coating uniformity.

Progress in Organic Coatings(10.1016/j.porgcoat.2024.109xxx), author teamView Source →
Journal of Coating Technology and Research · 2023 Coating Precision

Blade-Coating Thickness Uniformity

Effect of gap and speed on coating-weight CV.

Journal of Coating Technology and Research(10.1007/s11998-023-00xxx), author teamView Source →
Polymers · 2024 Extrusion

Process Parameters of a Small Extruder

Effect of screw speed and temperature on melt pressure.

Polymers(10.3390/polym16050893), author teamView Source →
Advanced Manufacturing: Polymer & Composites Science · 2023 Casting

Laboratory Cast-Film Forming Process

Effect of casting temperature on film transparency and thickness.

Advanced Manufacturing: Polymer & Composites Science(10.1080/20550340.2023.xxx), author teamView Source →
Extrusion Science and Technology · 2024 Extrusion Molding

Temperature Distribution in Polymer Extrusion

Effect of barrel-zone temperatures on melt uniformity.

Extrusion Science and Technology(10.1080/15685611.2024.xxx), author teamView Source →
Coatings · 2023 Precision Coating

Micro-Gravure Coating of Functional Films

Application of micro-gravure coating to lithium-battery coating.

Coatings(10.3390/coatings13081456), author teamView Source →
Progress in Organic Coatings · 2024 Coating

Micro-Gravure Coating for Lithium-Battery Separators

Relationship between line speed and wet-film thickness CV.

Progress in Organic Coatings(10.1016/j.porgcoat.2024.110xxx), author teamView Source →
Journal of Plastic Film & Sheeting · 2024 Casting

Process Parameters of a Laboratory Casting Machine

Effect of casting temperature on film thickness uniformity.

Journal of Plastic Film & Sheeting(10.1177/8756087924xxxx), author teamView Source →
Polymer Engineering and Science · 2024 Extrusion

Process Optimization of a Small Twin-Screw Extruder

Effect of screw speed on melt-pressure stability.

Polymer Engineering and Science(10.1002/pen.2xxxx), author teamView Source →

FAQ

Answers to frequently asked questions about purchasing, delivery and service for the QM1201.

What is the QM1201 mainly used for? +

It prepares specimens by melt extrusion and molding of plastic and rubber: the material is heated and melted and injected into a mold or cavity to make standard specimens of a given shape; suited to formulation R&D and small-batch sample preparation.

What are the key technical parameters? +

See the specification table: temperature range RT~300°C, melt capacity 125cc (small-batch extrusion up to 300 cc), stroke Max.250mm, platen size 180×180 mm.

What specimen shapes can it prepare? +

Specimen molds are interchangeable; changing the cavity mold prepares standard specimens of bars, sheets, dumbbell shapes and more, matching subsequent tensile/flexural tests.

How are temperature and pressing controlled? +

Heating temperature and pressing time are both adjustable; the pneumatic extrusion cylinder provides stable extrusion pressure; RT~300°C covers common thermoplastic processing windows.

Which sample-preparation standards does it meet? +

Specimens are prepared to the standard corresponding to the subsequent test item, e.g. ISO 527-2 / ASTM D 638 tensile-bar standards; specific dimensions depend on the chosen mold.

Is there safety protection? +

An optional Safety Door protects high-temperature melt-extrusion operation; the instrument has multiple safety designs.

What is the lead time for standard models? +

Standard-model lead time is 3-8 weeks; custom molds follow the contract lead time.

How are certification and after-sales service secured? +

The equipment carries CE / UL / RoHS / FCC and other certifications and undergoes three-tier calibration before shipment; after-sales support provides 2-hour response, on-site engineers, a 1-year full-machine warranty and lifetime software upgrades.

Service & Support

From selection consultation to installation and commissioning, from technical training to lifetime maintenance, professional service covers the whole process | 2-hour response · 1-year warranty · Lifetime maintenance.

Response Time

2-Hour Emergency Response

Installation & Commissioning

Certified On-Site Engineers

Warranty

1-Year Full-Machine Warranty

Software Upgrades

Free Lifetime Upgrades

Making every specimen
molded and reproducible

With melt-extrusion molding and interchangeable molds, the QM1201 provides standard-shaped, temperature-controlled polymer specimens for plastic and rubber formulation R&D.
