Mooney Viscometer

Materials Testing Instrument

Unvulcanized Rubber Mooney Viscosity & Scorch Test

Name: QMV2020
Brand: Br&Qmesys

QMV2020

The QMV-2020 Mooney viscometer is based on the KS M 6605 physical test method for unvulcanized rubber; it identifies the viscosity characteristics of unvulcanized polymers and raw materials on the production floor to guide mixing and formulation adjustments.

Automatic control program

Digital PID temperature controller

Calibration kit (standard)

Auto-sliding door

Compliant with KS M 6605, ASTM D 1646 and ISO 289

Request a Quote & Technical Proposal Download Technical Resources

✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide

100cpmOscillation Frequency

10~200°CTemperature Range

ASTM D1646Test Standards

Certifications

CE UL ISO 9001 RoHS FCC

Key Product Features

Rubber processing - authoritative research verifying the key role of vulcanization/mixing in rubber performance evaluation

Automatic Control Program

The whole test runs automatically and programmatically with no manual attendance, raising batch-test efficiency.

Digital PID Temperature Controller

Digital PID closed-loop temperature control with smooth ramp-up and small fluctuation; multi-segment editable programs meet different material process windows.

Calibration Kit

(standard)

Auto-Sliding Door

The test chamber door slides open/closed automatically, reducing the risk of hands entering the high-temperature cavity.

Compliant with KS M 6605, ASTM

D 1646 and ISO 289 standards

Mooney Viscometer
Unvulcanized rubber viscosity test

The QMV2020 Mooney viscometer measures Mooney viscosity, scorch time and vulcanization index of unvulcanized rubber. Digital PID temperature controller, automatic control program, auto-sliding door, calibration kit included, compliant with KS M 6605/ASTM D1646 rubber viscosity test standards.

From compounded rubber to vulcanization - Mooney viscosity after mixing directly affects processing flow and vulcanization behavior. Mooney viscosity is the core indicator of rubber processability: too high and processing is difficult, too low and finished parts perform poorly. Automatic measurement of viscosity-time curves makes it essential for incoming-material QC and compounded-rubber QC at rubber plants.

Designed for rubber processability - Mooney viscosity + scorch time, ASTM D1646 rubber testing.

▪Mooney viscosity/scorch/vulcanization index · full parameters
▪Digital PID control · automatic program
▪Auto-sliding door · safe and efficient
▪ASTM D1646/KS M 6605 · standard
▪Compounded/native/vulcanized rubber · viscosity test

Core Parameters

Mooney Viscometer

Temperature Range 10 ~ 200°C (optional: 230°C)

Rotor Speed 2rpm ±0.01

Accuracy Class Professional-grade

Applicable Standards International Certification

StandardKS M 6605, ASTM D 1646, ISO 289

Product Highlights

Automatic Control Program
Digital PID Temperature Controller
Calibration Kit (Standard)
Auto-Sliding Door
Compliant with KS M 6605, ASTM D 1646 and ISO 289
Designed & Made in Korea
Exported to 90+ Countries Worldwide

Typical Applications & Applicable Standards

Suitable for rubber mixing, tires, conveyor belts, seals and other applications, compliant with relevant international and national standards

Typical Applications

Rubber MixingTiresConveyor BeltsSealsIncoming-Material Inspection

Applicable Standards

KS M 6605

ASTM D1646

ISO 289

GB/T 1233

Technical Specifications

QMV2020 core parameters fully listed to support selection and evaluation

Model	QMV-2020
Temperature Range	10 ~ 200°C (optional: 230°C)
Rotor Speed	2rpm ±0.01
Standard	KS M 6605, ASTM D 1646, ISO 289
Size	544(W) x 590(D) x 1305(H)mm
Power Supply	AC 220V 50/60Hz
Operating Environment	10-35°C, ≤80%RH
Safety Protection	Overload Protection / Emergency Stop

Glossary

Mooney Viscosity: Viscosity index of unvulcanized rubber at a given temperature and shear
Scorch Time: Time at which the compound starts early vulcanization
Vulcanization: Crosslinking cure process of rubber

Viscosity Measurement

Rotational viscometer, low shear rate

Digital Display

Real-time speed and viscosity display

Wide Range

1~2,000,000 mPa·s

Programmable

Optional programmable stepped speed

Data Output

RS232 to PC

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.
