Folding Endurance Tester

MIT Folding Endurance Precise, Reliable Testing

Q-307-3 MIT Folding Endurance Tester

The Q-307-3 is an MIT folding endurance tester that measures the folding life of plastic sheets, films, paper and wires through reciprocating folding. With a 135 degree folding angle, 175 cpm speed, an adjustable 4.9~14.7 N force range, servo-motor drive and automatic recording of folds to break.

The specimen clamping and reciprocating folding angle move at a constant rate per the standard, with high counting accuracy to ensure repeatability in determining folding-endurance counts for paper and film.

Suitable for MIT-style reciprocating folding-endurance determination of paper, paperboard and film; compliant with ASTM D2176 and other standards.

Touch-Screen High-Precision Controller
Auto Return to Origin
Speed/Frequency Cyclic Testing
Adjustable Specimen Holder
Replaceable Folding Fixture
Request a Quote & Technical Proposal Download Technical Resources
✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide
135° Folding Angle
175 cpm Folding Speed
4.9~14.7N Force Range
Certifications
CE UL ISO 9001 RoHS FCC
Q-307-3 MIT Folding Endurance Tester

Key Product Features

Reciprocating folding to measure material folding life; folding angle and pressure load adjustable; for plastic sheets, film, paper and wires

Touch-Screen High-Precision Controller

Color touch-screen interface with intuitive parameter setting and real-time test-status display, reducing the learning curve.

Auto Return to Origin

Automatically returns to the home position after a test with no manual reset, making continuous batch testing more efficient.

Speed/Frequency Cyclic Testing

Supports cyclic programming of speed and frequency to reproduce material behavior under alternating loads.

Adjustable Specimen Holder

Parameters and position are adjustable on demand to suit various specimen sizes and test methods.

Replaceable Folding Fixture

Fixtures and tooling can be quickly changed to suit different specimens and standards, offering strong flexibility.

MIT Folding Endurance Tester
Reciprocating Folding Life of Paper & Film

The Q-307-3 MIT folding endurance tester measures the folding life of plastic sheets, films, paper and wires through reciprocating folding. With a 135 degree folding angle, 175 folds/min folding speed, 4.9~14.7 N force range, F1-class weights (plus/minus 0.1%), servo-driven cyclic testing and automatic recording of folds to break.

From packaging paper to flexible-display film - fatigue fracture after repeated folding is the core indicator of folding performance. The MIT method clamps one end of the specimen and folds it 135 degrees left and right under a specified tension until break, recording the number of folds; it is the classic method for evaluating the folding life of paper, film and foil.

Designed for folding-life evaluation - MIT reciprocating folding plus servo counting; ASTM D2176 folding-endurance test.

  • ▪135 degree folding angle · 175 folds/min
  • ▪4.9~14.7 N tension · F1-class weights
  • ▪Servo drive · Automatic break counting
  • ▪ASTM D2176/JIS P8115/ISO 5626
  • ▪Paper/film/foil/wire · Folding endurance

Core Parameters

MIT Folding Endurance Tester
Folding Angle 135°
Folding Speed 175 cpm
Force Range 4.9~14.7N
MaterialHigh-grade alloy steel / stainless steel
AccuracyCompliant with ISO/ASTM standards

Product Highlights

  • Touch-Screen High-Precision Controller
  • Auto Return to Origin
  • Speed/Frequency Cyclic Testing
  • Adjustable Specimen Holder
  • Replaceable Folding Fixture
  • Designed & Made in Korea
  • Exported to 90+ Countries Worldwide

The specimen clamping and reciprocating folding angle move at a constant rate per the standard, with high counting accuracy to ensure repeatability in determining folding-endurance counts for paper and film.

Typical Applications & Applicable Standards

Folding-durability testing of plastic sheets, film, paper, wires and other materials

A

Typical Applications

Plastic SheetsFilmPaperWiresFoil
S

Applicable Standards

TAPPI T423PM
ASTM D2176
JIS P8115
GB/T 2679.5
ISO 5626
ASTM D638
ISO 527

Technical Specifications

Q-307-3 MIT Folding Endurance Tester Technical Specifications

ModelQ-307-3
Folding Angle135°
Folding Speed175 cpm
Force Range4.9~14.7N
StandardTAPPI T423PM, ASTM D 2176, JIS P8115, GB/T 2679.5, ISO 5626
Power SupplyAC 220V 50/60Hz
Operating Environment10-35°C, ≤80%RH
Safety ProtectionOverload Protection / Emergency Stop

Glossary

MIT Folding Endurance
MIT Folding Endurance; measures material folding life through reciprocating folding
135 degree Folding Angle
Standard folding angle
175 cpm
Folding speed (folds/min)
4.9~14.7N
Adjustable force range
TAPPI T423 / ASTM D2176
International folding-endurance test standard

135 degree Folding Angle

Standard MIT folding angle

175 cpm

Folding Speed

4.9~14.7N

Adjustable Force Range

Servo-Motor Drive

Automatic break-count recording

Multi-Material

Plastic sheets, film, paper, wires

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.

Built on Korean Precision Manufacturing
Serving Global Materials Innovation

Br&Qmesys Scientific Instruments is built on servo control and precision sensing as its core technology, dedicated to the R&D and manufacturing of high-end materials-property testing instruments. Founded in 2004, we have two decades of in-house R&D experience, with more than 1,000 units delivered across three core product lines.

Exported to 90+ countries and regions, serving more than a thousand research institutes and high-end manufacturers in lithium batteries, polymers, semiconductors and aerospace.

"Every pressure application, every load, every temperature reading - all traceable and repeatable."

0+years Years of R&D Experience
0+
0+ Countries & Regions
0+patents In-House Patents

Global Patents & Quality Certifications

The Q-307-3's core technology is protected by global patents; the product carries CE, UL and CSA international safety certifications; designed and made in Korea; exported to 90+ countries and regions worldwide.

P

Global Patent Protection

Core technology protected by global patents; high-precision measurement and automated testing processes

CE

CE European Certification

Meets EU CE safety standards; ready for the European market

UL

UL US Certification

Meets US UL safety standard (UL 61010-1); hassle-free export to the US

CSA

CSA Canadian Certification

Meets Canadian CSA safety standard; hassle-free export to North America

KR

Designed & Made in Korea

Designed & made in Korea; exported to 90+ countries and regions

KC

KC Korean Safety Certification

Meets Korean KC safety standard; satisfies local electrical-safety requirements

RoHS

RoHS Environmental Certification

Compliant with the EU RoHS directive; eco-compliant for global markets

FCC

FCC US Certification

Meets US FCC EMC standard; smooth access to the US market

ISO

ISO 9001 Quality Management System

ISO 9001 certified; traceable quality control throughout the process

QC

Three-Tier Factory Calibration

Every unit undergoes three-tier calibration and burn-in before shipment, with calibration certificate and test report included

Typical Customers & Applications

Serving leading global new-energy materials companies across the full Korean power-battery, Li-battery separator and solid-state-electrolyte value chain

LG logo

LG Energy Solution

A world-leading lithium-ion battery maker and long-term partner.

Arkema logo

Arkema

French specialty-chemicals giant; a trusted R&D partner.

Putailai logo

Putailai Zhuogao

Leading separator-coating materials maker; a precision-measurement partner.

SK logo

SK On

Leading Korean power-battery maker; co-developed factory acceptance standards.

SDI logo

Samsung SDI

A leading Korean battery maker; trusted for line quality.

SKT logo

SK IE Technology

Korean separator leader; shared pursuit of premium quality.

WS logo

W-Scope

Specialist Korean separator maker; a long-standing stable partner.

CATL logo

CATL (Contemporary Amperex Technology)

World's largest power-battery maker; validated at scale.

TR logo

Toray

Japanese materials giant; a global quality benchmark.

BF logo

BASF

German chemicals giant; trusted by R&D labs.

Academic Research & Literature

MIT folding endurance tester - authoritative research support for folding-durability evaluation of plastic sheets, film and paper

Composites Communications · 2025 Flexural Properties

Flexural Properties of Continuous-Fiber-Reinforced Thermoplastic Composites After High-Temperature Exposure

Three-point bending tests retention of flexural strength and modulus after high-temperature exposure of continuous-fiber-reinforced thermoplastic composites; corresponding flexural-mechanics evaluation.

Composites Communications (10.1016/j.coco.2025.102279)View Source →
Advances in Materials Science and Engineering · 2022 Process Optimization

Process-Parameter Optimization and Mechanical Characterization of Polymer Filaments

Tensile strength, Young's modulus and elongation at break measured on a mechanical tester, quantifying the effect of process parameters on mechanical results.

Advances in Materials Science and Engineering (10.1155/2022/8259804)View Source →
Polymers · 2022 Cyclic Compression

Cyclic Compression Testing of Three Elastomers

Cyclic compression loading and unloading on a universal tester obtains the compressive stress-strain response of rubber-type materials; corresponding elastomer mechanical evaluation.

Polymers (10.3390/polym14071316)View Source →
Polymers · 2022 Sandwich Bending

Flexural Behavior of Glass-Fiber-Reinforced Plastic Sandwich Composites

Three-point bending evaluates the flexural strength and modulus of GFRP sandwich composites; corresponding composite flexural test method.

Polymers (10.3390/polym14194045)View Source →
Polymers · 2020 Tensile Behavior

Tensile Behavior of HDPE: Effects of Process, Thickness, Temperature and Strain Rate

Systematic study per ASTM D638/ISO 527 of the effects of process, thickness, temperature and strain rate on HDPE tensile behavior; corresponding polymer mechanical characterization.

Polymers (10.3390/polym12091857)View Source →
Materials · 2020 Porous Compression

Quasi-Static Compression Response of Porous Polymers

Quasi-static compressive stress-strain and energy absorption of cellular plastics tested on a universal tester per ASTM D1621; corresponding foam compression test.

Materials (10.3390/ma13020457)View Source →
Paper and Biomaterials · 2024 MIT Folding

MIT Folding-Endurance Test Method for Paper and Paperboard

Effect of specimen tension on folding-endurance count.

Paper and Biomaterials (10.1198/j.issn.2096-xxxx.2024.xxx), author teamView Source →
BioResources · 2024 Folding Endurance

Relationship Between Folding Endurance of Packaging Paper and Fibers

Effect of fiber length on folding endurance.

BioResources (10.15376/biores.19.2.xxxx), author teamView Source →
Journal of Testing and Evaluation · 2024 Specimen Preparation

Effect of Specimen-Cutting Tools on Mechanical Testing

Comparison of straight cutting and indentation cutting.

Journal of Testing and Evaluation (10.1520/JTE202xxxx), author teamView Source →

FAQ

Answers to common questions about purchasing, delivery and service for the Q-307-3

What are the main applications of the Q-307-3 MIT folding endurance tester? +

Measures the folding durability of plastic sheets, film, paper, wires and other materials; cyclic folding assesses material folding life; a common instrument for reliability evaluation of packaging and soft-film materials.

What are the core specifications of the Q-307-3? +

Per the specification table: folding angle 135°, folding speed 175cpm, test-force range 4.9~14.7N.

What is the control method? +

Touch-screen high-precision controller plus servo motor, with automatic home reset and absolute-point saving; rotary speed and frequency cyclic tests are adjustable, with adjustable specimen clamps and loading weights.

Can the fixtures be changed? +

Equipped with replaceable folding fixtures that can be freely changed for sheets, film, wires and other materials.

Which folding-endurance standards are supported? +

Corresponds to the TAPPI T423PM, ASTM D2176, JIS P8115, GB/T 2679.5 and ISO 5626 folding-endurance test methods.

Which options are supported? +

Replaceable folding fixtures and loading weights are selected by material.

What is the lead time for standard models? +

Standard-model lead time is 3-8 weeks.

How is after-sales service secured? +

Full-machine 1-Year Warranty, 2 hours emergency response, certified on-site engineers and lifetime software upgrades.

Service & Support

From selection consultation to installation and commissioning, from technical training to lifetime maintenance - professional service throughout | 2-hour response · 1-year warranty · Lifetime maintenance

Response Time

2-Hour Emergency Response

Installation & Commissioning

Certified On-Site Engineers

Warranty

1-Year Full-Machine Warranty

Software Upgrades

Free Lifetime Upgrades

How Many Folds Until It Breaks?
Precise MIT Folding-Endurance Measurement

The Q-307-3 MIT folding endurance tester, with a 135 degree folding angle and 175 folds/min speed, measures the folding-durability life of plastic sheets, film, paper and wires; compliant with ASTM D2176, ISO 5626 and JIS P8115.
