Low-Pressure Precision Forming · Medical / Electrode Coating

Hot Press Forming Machines

Pressure-Free Air-Heated Forming ±0.2 kgf · Low-Pressure Precision

Name: QM940AT
Brand: Br&Qmesys

QM940AT Small Pressure-Free Precision Forming Platen

The QM940AT small pressure-free precision forming platen uses air heating with excellent temperature uniformity and platen flatness. A load cell delivers fine ±0.2 kgf pressure control for low-pressure hot pressing of medical diagnostic kits and electrode-material coatings; LM rails and a vacuum forming plate are optional.

When too much pressure damages the sample - the ±0.2 kgf fine control protects delicate coatings and films.

±0.2 kgf Fine Pressure Control
· Load cell

Max 0.6 t low pressure
· Medical / electrode coating

High-Precision LM Rails
· Optional vacuum plate

Excellent Temperature Uniformity
· High platen flatness

Request a Quote & Technical Proposal Download Technical Resources

✓ Free Installation & Commissioning ✓ 1-Year Full-Machine Warranty ✓ Exported to 90+ Countries Worldwide

±0.2kgfForming Method

Max. 0.6tLM Rails

Optional Vacuum PlateOptional

Certifications

CE UL ISO 9001 RoHS FCC

Key Product Features

A low-pressure precision forming platform - a ±0.2 kgf load cell with LM rails - delivers accurate low-pressure hot pressing for delicate coatings and films.

±0.2 kgf Fine Pressure Control

A high-precision load cell feeds back pressure in real time with ±0.2 kgf control accuracy - ideal for medical diagnostics, electrode coatings and other low-pressure applications.

High-Precision LM Rails

Precision linear-rail drive runs smoothly with minimal clearance; platen flatness stays high and accuracy holds over long service.

Excellent Temperature Uniformity

Air heating gives good platen temperature uniformity and high flatness, ensuring films/coatings heat uniformly.

Optional Vacuum Forming Plate

A vacuum forming plate can be fitted for special low-pressure hot pressing and vacuum forming, expanding applications.

Transparent Safety Door

An interlocked transparent safety door prevents accidental contact during operation and lets you observe the forming process, meeting industrial safety standards.

Low-Pressure Precision Forming
Protecting Delicate Coatings & Films

The QM940AT small pressure-free platen uses air heating; a load cell gives ±0.2 kgf fine pressure control for low-pressure hot pressing of medical diagnostic kits and electrode coatings. LM rails and a vacuum forming plate are optional.

When too much pressure damages the sample - the ±0.2 kgf fine control achieves precise hot-press bonding without harming the sample.

Designed for medical diagnostics and electrode coatings - ±0.2 kgf fine pressure control, the reliable choice for low-pressure applications.

▪±0.2 kgf fine pressure control · load cell
▪Max 0.6 t low pressure · medical / electrode coating
▪High-precision LM rails · optional vacuum plate
▪Excellent temperature uniformity · high platen flatness
▪Transparent safety door · visual observation

Core Parameters

Air-Heated Forming Platen

Temperature Range RT ~ 250°C

Pressure System Pneumatic Cylinder System

Cooling System Natural Cooling

MaterialHigh-grade alloy steel / stainless steel

AccuracyCompliant with ISO/ASTM standards

Product Highlights

Low-pressure samples only (max 0.6 t)
High-precision LM rails
Fine pressure control (±0.2 kgf)
High-precision load-cell system
Interlocked transparent safety door
Designed & Made in Korea
Exported to 90+ Countries Worldwide

Typical Applications & Applicable Standards

For medical diagnostic kits, electrode coatings, low-pressure hot pressing and vacuum forming; compliant with relevant international and national standards.

Typical Applications

Medical Diagnostic KitsElectrode CoatingsLow-Pressure Hot PressingVacuum Forming

Applicable Standards

ASTM D4703

ISO 293

Medical Industry Standards

Technical Specifications

Core parameters of the air-heated forming platen are fully specified to support selection and evaluation.

Model	QM940AS (Electrode)	QM940AS (Standard)	QM940AT
Temperature Range	RT ~ 250°C
Pressure	Max 2.5 t (air input 8 kgf/cm²)	Max 2.5 t (air input 8 kgf/cm²)	Max 0.6 t (air input 8 kgf/cm²)
Pressure System	Pneumatic Cylinder System
Platen Size	100 x 100 mm (Teflon-coated)	200 x 200mm	200 x 200mm
Cooling System	Natural Cooling
Size	650(W) x 810(D) x 1750(H)mm	650(W) x 810(D) x 1750(H)mm	500(W) x 450(D) x 1100(H)mm
Power Supply	AC 220V 50/60Hz
Operating Environment	10-35°C, ≤80%RH
Safety Protection	Overload Protection / Emergency Stop

Glossary

Pressure-Free Forming: Forming by heat and self-weight only; no external pressure applied
Vacuum Forming: Vacuum draws the material against the forming surface
Load Cell: Sensor that measures pressure in real time

Air-Heated Platen

Small pressure-free forming; uniform temperature

RT~300°C

High-precision temperature control with small fluctuation

Natural Cooling

Simple structure; easy maintenance

Small & Compact

Benchtop lab model; small footprint

Safety Protection

Over-temperature protection; leakage protection

Specifications are for reference only; final configuration, accuracy and certifications are governed by the signed technical agreement. Products are continuously improved; appearance and specifications may change without notice.
